  • NEMA size 11 (28mm square) step motor
  • Drive, controller and I/O built in
  • Three stack lengths
  • Holding torque from 8.3 to 16.7 oz in
  • Robust RS485 communication
  • Short lead time
  • Up to 16 units daisy chained
  • Economically priced
  • Simple yet highly functional command language
  • No charge Accuriss programming environment for PC's
  • Starter Kits available

DescriptionProduct DrawingsSpecificationsSpeed / TorqueWiringCAD DrawingsDownloadsVideos

The Accuriss 28, as the name implies, is 28mm square. The product is available in three stack lengths, with holding torques ranging from 8.3 to 16.7 oz. in. The Accuriss 28 mounting is the standard NEMA 11 mount. The Accuriss product line can be device addressed with up to 16 devices operating off of a single RS485 interface. The part number calls out the factory preset device address.

The device drivers for your USB, the Accuriss programming environment, the Accuriss 28 User Manual, along with all CAD files are readily available at no charge on this web site. To provide immediate implementation of the Accuriss 28, USAutomation offers a start up kit which contains, a USB to RS485 converter, a breakout board including I/O devices, a connector for the Accuriss, and a CD with everything you need to get started.
